FLURO®-GELENKLAGER GMBH
Rod End Bearings
MS - Series Bearings
MS - Series Bearings
MS - Series Bearings
MS - Series Bearings
MS - Series Bearings

MS - Series Bearings

PRELOADED BEARING FIT:
An internal play with 'zero' tolerance is achieved through a preloaded bearing. Under normal permissible conditions and usage a minimal settlement of the bearing components or a minimal
tolerance increase at the mating surface will take place. This special bearing technology causes a considerably higher bearing life with continuous low internal clearance. However MS - spherical plain
bearings are not suited for rotation as well as very high swivel frequency. Please note that the series GXO..ICR(RR) is not a preloaded bearing version, but the clearance is
reduced to a minimal fit.

SURFACE:
The nickel plated housing surface with a high polish finish achieves a sporty appealing design, especially on visible components. This high-quality surface treatment with high corrosion resistance
minimizes the sedimentation of dirt and is easy to clean.

LUBRICATION:
Maintenance free rod ends and spherical plain bearings must not be lubricated. The ball revolves on a PTFE liner incorporated in the insert.

EXAMINATION:
Upon customer requirements the parts can be checked against cracks.
